UX-V30
3-19
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 05
A
R 315 NRSA02J-100X MG RESISTOR 10 5% 1/10W
R 316 NRSA02J-223X RES. C.M 22K 5% 1/10W
R 317 NRSA02J-100X MG RESISTOR 10 5% 1/10W
R 319 NRSA02J-152X MG RESISTOR 1.5K 5% 1/10W
R 322 NRSA02J-152X MG RESISTOR 1.5K 5% 1/10W
R 327 NRSA02J-474X MG RESISTOR 470K 5% 1/10W
R 332 NRSA02J-123X RES. C.M 12K 5% 1/10W
R 333 NRSA02J-123X RES. C.M 12K 5% 1/10W
R 335 NRSA02J-152X MG RESISTOR 1.5K 5% 1/10W
R 336 NRSA02J-472X RES. C.M 4.7K 5% 1/10W
R 337 NRSA02J-332X MG RESISTOR 3.3K 5% 1/10W
R 338 NRSA02J-392X MG RESISTOR 3.9K 5% 1/10W
R 339 NRSA02J-222X MG RESISTOR 2.2K 5% 1/10W
R 340 NRS181J-391X MG RESISTOR 390 5% 1/8W
R 341 NRSA02J-123X RES. C.M 12K 5% 1/10W
R 342 NRSA02J-203X MG RESISTOR 20K 5% 1/10W
R 343 NRSA02J-183X MG RESISTOR 18K 5% 1/10W
R 351 NRSA02J-683X MG RESISTOR 68K 5% 1/10W
R 352 NRSA02J-912X RES. C.M 9.1K 5% 1/10W
R 371 NRSA02J-123X RES. C.M 12K 5% 1/10W
R 372 NRSA02J-102X RES. C.M 1.0K 5% 1/10W
R 375 NRSA02J-151X MG RESISTOR 150 5% 1/10W
R 376 NRSA02J-472X RES. C.M 4.7K 5% 1/10W
VR 31 QVP0008-503Z SEMI V RESISTOR BIAS ADJ
VR 32 QVP0008-503Z SEMI V RESISTOR BIAS ADJ
VR 37 QVP0008-103Z SEMI V RESISTOR TAPE SPEED ADJ
(Head amp board)
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 06
A
CN 1 QGB2011L1-10 10P PLUG ASSY
D 1 1SR139-400-T2 SI DIODE
IC 1 SG-105F3-BB,C PHOTO SENSER
P 1 QNZ0104-001 POST PIN
SW 1 QSW0832-001 CASSETTE SWITCH R.REC
SW 2 QSW0832-001 CASSETTE SWITCH TAPE
SW 4 QSW0832-001 CASSETTE SWITCH 70U
SW 5 QSW0832-001 CASSETTE SWITCH F.REC
SW 6 QSW0859-001 SWITCH
(Switch board)
