Troubleshooting
Symptom Action
Camera image is not output on
the viewfinder screen.
0
Is the CONTRAST knob on the viewfinder set to the minimum?
Adjust the [CONTRAST] knob on the viewfinder.
Specifications
General
Item Description
Power DC 12 V 0.5 A
* Power supplied from the
camera
Mass Approx. 750 g
Allowable operating
temperature
0 ℃ to 40 ℃ (32 °F to 104 °F)
Allowable operating
humidity
30 %RH to 80 %RH
Allowable storage
temperature
-20 ℃ to 50 ℃ (-4 °F to 122 °F)
Drip-proof
performance
Equivalent to IPX2
Display panel 3.26-inch OLED WVGA (854 ×
480)
Accessories
Accessories
Warranty Card (for USA) 1
INSTRUCTIONS 1
* The warranty card is included in the instruction
manual.
Dimensional Outline Drawing (Unit: mm)
.
* The specifications and appearance of this product are subject to changes for further improvement
without prior notice.
10 EN
