JVC VS-DT9R Service Manual

VS-DT9R/VS-DT6R
VS-DT9R/VS-DT6R
3-4
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 GV10091-001A
MOVING BASE
1
2 GV40269-001A
ROLLER
4
3 GV10092-002A
MOVING PANEL
1
4 GV30361-001A
SHIELD(A)
1
FOR MOVING PANE
5 GV30362-001A
SHIELD(B)
1
FOR FL PWB
6 E3400-431
SPACER
1
7 GV40334-001A
SHEET
1
8 GV40356-001A
SHEET
1
9 GV30238-005A
FRONT LENS
1
10 QYSBSF2608Z
T.SCREW
2
FL PWB
11 QYSBSF2608Z
T.SCREW
2
M.PANEL+M.BASE
12 GV10090-001A
FRONT BASE
1
13 GV30235-002A
FELT
1
CD SLOT
14 GV40269-001A
ROLLER
2
FRONT BASE
15 GV30308-001A
ROD GEAR ASS'Y
1
16 QYSBSF2608Z
T.SCREW
4
SW PWB
17 QYSBSF2608Z
T.SCREW
2
M BKT ASY+F.BAS
18 GV30237-002A
MOTOR BKT ASSY
1
FOR FL
19 LV42436-001A
WORM GEAR
1
20 GV40266-001A
ROTOR
1
21 GV40267-002A
GEAR 1
1
22 GV40338-001A
GEAR 2 1
23 LV30981-005A
CLUTCH ASS'Y
1
24 QYWFL266010-9
WASHER
1
CLUTCH
25 WDM214540
WASHER 3
GEAR/CLUTCH
26 QAR0220-001
DC MOTOR
1
27 QYSPSPT2020Z
MINI SCREW
2
DC MOTOR+M.BKT
28 QYSBST2604Z
T.SCREW
1
OPEN/CLOSE PWB
29 GV10093-001A
BOTTOM CHASSIS
1
30 VYSA1R4-050
SPACER
1
FOR BOTTOM CHAS
31 QYSBST4006Z
T.SCREW
2
BOTTOM+TRANS
32 QYWSS431010Z
WASHER
2
FOR POWER TRANS
33 GV30239-001A
H.PHONE COVER
1
34 GV40347-001A
WIRE HOLDER
1
35 QYSBSG3006E
T.SCREW
4
BOTTOM+MAIN PWB
36 QYSBSG3008Z
T.SCREW
2
BOTTOM+F.BASE
37 QYSBSG3008M
T.SCREW
1
MAIN PWB+H.P CO
38 GV30336-001A
BARRIER(A)
2
FOR PRIMARY CIR
39 GV30337-001A
BARRIER(B)
2
FOR 15 WATT LIN
40 QAR0148-001
FAN MOTOR
1
41 GV40354-001A
FAN COVER
1
42 VYSA1R4-050
SPACER
1
FOR FAN MOTOR W
43 LV30225-011A
SPACER
1
FOR FAN MOTOR W
44 QYSBSGG3014Z
SCREW
2
FAN+B.CHASSIS
45 GV10096-001A
TOP PANEL
1
VS-DT6R
GV10096-002A
TOP PANEL 1
VS-DT9R
46 GV40122-005A
FOOT SPACER
2
47 GV30245-001A
LIGHT LENS
1
48 GV30342-002A
TOP LENS B ASSY 1
VS-DT6R
49 GV10095-001A
TOP CHASSIS
1
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
50 GV40333-001A
SPACER
1
51 GV40330-001A
SPACER
1
STICK ON TOP CH
52 GV20159-001A
PUSH BUTTON
1
53 QYSBSG3008Z
T.SCREW
3
TOP C+MECHA
54 ---------------
CD MECHA
1
FMU-F1-1M
55 GV20186-001A
PROTECTOR
1
FOR SLOT IN CD
56 QYSBSF2006Z
SCREW
1
PROTECTOR + CD
57 QYSBST3006Z
SCREW
1
58 QYSSST3006E
SCREW
5
TOP.C+B.CHASSIS
59 GV30244-001A
IC HOLDER
1
60 QYSBSG3014Z
T.SCREW
2
IC+IC HOLDER
61 GV30243-001A
HEAT SINK
1
62 QYSBSG3008Z
T.SCREW
2
DIODE+H.SINK
63 QYSBSG3008Z
T.SCREW
2
TR+H.SINK
64 QYSBSG3008M
T.SCREW
3
LATER REJECT CENTER SCREW
65 QYSBSGY3008E
SPECIAL SCREW
1
BOTTOM+H.SINK
66 QYSBSG3006Z
T.SCREW
1
TUNER PWB+TOP C
67 GV20165-008A
REAR PANEL
1
68 GV40329-001A
SPACER
1
ROLL MAIN-TOP W
69 QYSBSG3008M
T.SCREW
2
TUNER
70 QYSBSG3008M
T.SCREW
2
SPK
71 QYSBSG3008M
T.SCREW
1
72 QYSBSG3008M
T.SCREW
1
OPT OUT
73 QYSBSG3008M
T.SCREW
1
AC IN
74 GV10094-002A
BOTTOM PANEL
1
75 GV40270-001A
FOOT
4
B.PANEL(FOOT)
76 QYSBSG3008M
T.SCREW 3
R.PANEL+B.PANEL
77 QYSBSG3008M
T.SCREW
2
B.CHA+B.PANEL
78 GV30249-007A
RATING LABEL
B,E,EN
A
1
VS-DT6R
GV30250-008A
RATING LABEL
EV
A
1
VS-DT9R
GV30250-007A
RATING LABEL
B,E,EN
A
1
VS-DT9R
GV30249-008A
RATING LABEL
EV
A
1
VS-DT6R
79 QQT0366-003
POWER TRANSF
A
1
T1901
80 GV30357-001A
SHIELD
1
FOR POWER TRANS
81 GV40344-001A
SPACER
1
STICK ON SHIELD
82 QMF51W2-6R3-J8
FUSE
A
1
F1902
83 QMF51W2-3R15-J8
FUSE
A
1
F1903
84 QMF51W2-R50-J8
FUSE
A
1
F1901
85 GV40328-001A
SPACER
2
86 GV40268-002A
SPACER
2
TOTAL THICKNESS
87 QUQ610-1717BJ
FFC WIRE
1
PANEL - MAIN
88 QUQ412-1308DJ
FFC WIRE
1
TUNER -MAIN
89 WJT0074-001A
E-CARD WIRE
1
SW - MAIN
90 WJM0133-003A
SIN CR C-B WIRE 1
DC MOTOR - MAIN
91 E3400-431
FELT SPACER
2
92 GV40340-001A
PLATE ASSY
1
VS-DT9R
93 GV20157-002A
TOP LENS 1
VS-DT9R
94 LV42860-001A
SPECIAL SCREW
4
VS-DT9R
96 GV40170-001A
SPACER
2
97 GV30349-002A
SPACER 1
