XV-M565BK/M567GD
3-9
Item
Parts number Parts name
Area
A
Parts list (DVD mechanism)
Q'ty
Description
Block No. M3MM
1 LV20463-001A MECHA BASE 1
2 LV31286-001A SHAFT HOLDER 1 1
3 LV31287-001A SHAFT HOLDER 2 1
4 LV31288-001A SHAFT HOLDER 3 1
5 QYSBST2005Z T.SCREW 4 SHAFT HOLDER
6 VDG1081-001TT5 SP.MOTOR BKT AS 1 ASS'Y
13 QAL0186-001 DVD PICK UP
A
1
14 LV31285-002A RACK BASE 1 FOR DVD PICK
15 LV41109-001A R.BASE SPRING 1 FOR RACK BASE
16 QYSPSPU1740M SCREW 1 FOR RACK BASE
17 LV31359-001A P.U. SPRING 1 FOR DVD PICK
18 LV41021-001A SPECIAL SCREW 1 FOR P.U.SPRING
19 LV41121-001A SHAFT 2
20 LV41115-002A SPRING 3 FOR TILT
22 LV31283-002A S.HOLDER BKT 2 FOR S.HOLDER2
23 QYSSST2615Z TAP SCREW 3 MOTOR BKT
24 QYSDST2616Z SCREW 2 S.H.BKT*2
25 LV41111-002A FPC HOLDER 1
30 QAR0106-001 FEED MOTOR 1
31 VKZ4539-026 MINI SCREW 2 FOR F.MOTOR
32 QYYASPF2610N SCREW 3 FOR TILT
33 QYSBST2005Z T.SCREW 2 FOR PW.BORD
36 LV41479-002A RACK COVER 1
