XV-M565BK/M567GD

3-10

Electrical Parts List

Item

Parts number Parts name Area

Electrical parts list ( Main board )

Remarks

Block No. 01

C 601 QCS11HJ-181 C CAPACITOR 180PF 5% 50V

C 603 QCS11HJ-680 C CAPACITOR 68PF 5% 50V

C 604 QCS11HJ-150 C CAPACITOR 15PF 5% 50V

C 609 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 611 QCS11HJ-181 C CAPACITOR 180PF 5% 50V

C 613 QCS11HJ-680 C CAPACITOR 68PF 5% 50V

C 614 QCS11HJ-150 C CAPACITOR 15PF 5% 50V

C 619 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 621 QCS11HJ-121 C CAPACITOR 120PF 5% 50V

C 623 QCS11HJ-470 C CAPACITOR 47PF 5% 50V

C 624 QCS11HJ-100 C CAPACITOR 10PF 5% 50V

C 629 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 631 QCS11HJ-121 C CAPACITOR 120PF 5% 50V

C 633 QCS11HJ-470 C CAPACITOR 47PF 5% 50V

C 634 QCS11HJ-100 C CAPACITOR 10PF 5% 50V

C 639 NCB21EK-104X C CAPACITOR

C 641 QCS11HJ-121 C CAPACITOR 120PF 5% 50V

C 643 QCS11HJ-470 C CAPACITOR 47PF 5% 50V

C 644 QCS11HJ-100 C CAPACITOR 10PF 5% 50V

C 649 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 659 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 701 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 702 NCB21EK-104X C CAPACITOR

C 703 QETN1CM-226Z E CAPACITOR 22MF 20% 16V

C 704 NCB21EK-104X C CAPACITOR

C 705 NCB21EK-104X C CAPACITOR

C 706 QFVF1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 707 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 708 NCB21EK-104X C CAPACITOR

C 709 NCS21HJ-331X C CAPACITOR

C 710 QETN1AM-477Z E CAPACITOR 470MF 20% 10V

C 711 QCZ0205-155Z ML C CAPACITOR 1.5MF

C 712 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 714 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 715 QCZ0205-155Z ML C CAPACITOR 1.5MF

C 716 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 717 QCZ0205-155Z ML C CAPACITOR 1.5MF

C 718 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 720 NCB21EK-104X C CAPACITOR

C 721 QCZ0205-155Z ML C CAPACITOR 1.5MF

C 722 QCF11HZ-473 C CAPACITOR .047MF +80:-20%

C 724 QCF11HZ-103 C CAPACITOR .010MF +80:-20%

C 725 QETN1CM-477Z E CAPACITOR 470MF 20% 16V

C 726 QETN1CM-227Z E CAPACITOR 220MF 20% 16V

C 727 QETN1AM-227Z E CAPACITOR 220MF 20% 10V

C 728 QETN1AM-107Z E CAPACITOR 100MF 20% 10V

C 730 QFVJ1HJ-474Z CAPACITOR .47MF 5% 50V

C 731 QDYB1CM-103Y C.CAPACITOR

C 732 QDGB1HK-102Y C CAPACITOR

C 733 QDGB1HK-102Y C CAPACITOR

C 734 QDX31EM-473Z C.CAPACITOR

C 735 NCB21EK-104X C CAPACITOR

C 736 NCB21EK-104X C CAPACITOR

C 740 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V

C 741 QFLC1HJ-181Z M.CAPACITOR 180PF 5% 50V

C 742 QFN31HJ-333Z M.CAPACITOR .033MF 5% 50V

C 743 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V

C 744 QFLC1HJ-182Z M CAPACITOR 1800PF 5% 50V

C 745 QFN31HJ-103Z M CAPACITOR .010MF 5% 50V

C 746 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 747 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V

C 750 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V

C 751 QFLC1HJ-181Z M.CAPACITOR 180PF 5% 50V

C 752 QFN31HJ-333Z M.CAPACITOR .033MF 5% 50V

C 753 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V

C 754 QFLC1HJ-182Z M CAPACITOR 1800PF 5% 50V

C 755 QFN31HJ-103Z M CAPACITOR .010MF 5% 50V

C 756 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 757 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V

C 761 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 762 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 771 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 772 QETN1CM-107Z E CAPACITOR 100MF 20% 16V

C 797 NCB21HK-103X C CAPACITOR

C 798 NCB21HK-103X C CAPACITOR

C 801 NCB21EK-104X C CAPACITOR

C 802 QEKC1AM-476Z E.CAPACITOR 47MF 20% 10V

C 811 NCB21EK-104X C CAPACITOR

C 812 QEKC0JM-476Z E.CAPACITOR 47MF 20% 6.3V

C 813 NCB21EK-104X C CAPACITOR

C 814 NCS21HJ-220X C CAPACITOR

C 821 QEKC1HM-475Z E.CAPACITOR 4.7MF 20% 50V

C 902 QFZ9067-683 C CAPACITOR

.068MF

C 906 QCZ9079-102 C CAPACITOR

1000PF

C 907 QETM2DM-157 E CAPACITOR

150MF 20%

C 908 QCZ0136-332Z C CAPACITOR 3300PF

C 909 QCZ0136-101Z C CAPACITOR 100PF

C 910 QCS11HJ-221 C CAPACITOR 220PF 5% 50V

C 913 QCZ0136-221Z C CAPACITOR 220PF

C 914 QEMX1EM-396Z E CAPA I/M 39MF 20% 25V

C 915 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V

C 916 QCZ9079-332 C CAPACITOR

3300PF

C 917 QCZ0205-155Z ML C CAPACITOR 1.5MF

C 918 QCFB1HZ-104Y C CAPACITOR .10MF +80:-20%

C 931 QCZ0205-155Z ML C CAPACITOR 1.5MF

C 951 QCS11HJ-101 C CAPACITOR 100PF 5% 50V

C 952 QCS11HJ-101 C CAPACITOR 100PF 5% 50V

C 953 QCS11HJ-101 C CAPACITOR 100PF 5% 50V

C 954 QCS11HJ-101 C CAPACITOR 100PF 5% 50V

C 956 QCS11HJ-101 C CAPACITOR 100PF 5% 50V

C 957 QCS11HJ-101 C CAPACITOR 100PF 5% 50V

C 960 QEMX1AM-826Z E CAPA. I/M 82MF 20% 10V

C 961 QCZ0205-155Z ML C CAPACITOR 1.5MF

C 962 QETN1HM-226Z E CAPACITOR 22MF 20% 50V

C 963 QEMX1HM-396Z E CAPA I/M 39MF 20% 50V

C 964 QETN1HM-226Z E CAPACITOR 22MF 20% 50V

C 965 QEMV1AM-108 E CAPACITOR 1000MF 20% 10V

C 966 QETN1AM-477Z E CAPACITOR 470MF 20% 10V

C 967 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 968 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 969 QETN1AM-227Z E CAPACITOR 220MF 20% 10V

C 970 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 973 QETN1AM-107Z E CAPACITOR 100MF 20% 10V

C 974 QETN1AM-107Z E CAPACITOR 100MF 20% 10V

C 976 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 977 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V

C 978 QETN1AM-107Z E CAPACITOR 100MF 20% 10V

C 979 QEMV1CM-827 E CAPACITOR 820MF 20% 16V

C 981 QCZ0205-155Z ML C CAPACITOR 1.5MF

C 982 QEMV1EM-567 E CAPACITOR 560MF 20% 25V

C 984 QETN1EM-227Z E CAPACITOR 220MF 20% 25V

C 987 QEMX1EM-187Z E CAPA I/M 180MF 20% 25V

C 989 QETN1EM-107Z E CAPACITOR 100MF 20% 25V

C 992 QETN1HM-474Z E CAPACITOR .47MF 20% 50V

C 993 QCS11HJ-101 C CAPACITOR 100PF 5% 50V

C 994 QDVB1EZ-223Y C CAPACITOR

Item

Parts number Parts name Area

Remarks
