XV-M565BK/M567GD
3-7
Item
Parts number Parts name
Area
A
Parts list (DVD changer mechanism)
Q'ty
Description
Block No. M2MM
1 VKS1144-003 CHASSIS 1
2 VKS3698-003 TRAY GUIDE 2
3 VKS5532-003 PULLEY GEAR 2
4 VKB3000-164 BELT 2
5 VKS5505-003 GEAR B 2
6 VKS5506-002 GEAR C 3
7 VKS5507-002 CROSS GEAR U 1
8 VKS5508-002 CROSS GEAR L 1
9 VKS5510-003 SELECT LEVER 1
10 VKH5769-001 S.G.SHAFT 1
11 VKS5511-002 SELECT GEAR 1
12 VKW5155-003 COMP.SPRING 1 FOR SELECT GEAR
13 VKM3846-002 GEAR BRACKET 1
14 VKS5509-002MM CYLINDER GEAR 1
15 MSN-5D257A-SA2 D.C.MOTOR 2
16 QYSPSPD2616Z SCREW 2 FOR MOTOR
17 LV40612-001A COMP.SPRING 1
18 VKM3825-00AMM C.G.BASE ASS'Y 1
19 VKZ3172-00ASS CAM SW. R ASS'Y 1
20 VKZ3173-00ASS CAM SW. L ASS'Y 1
21 QYSPST2606Z SCREW 4 FOR CAM SW.
22 VKS2263-002MM CAM R1 1
23 VKS2264-002MM CAM R2 1
24 VKS2265-002MM CAM GEAR L 1
25 WDL316050MM SLIT WASHER 2
27 QYSBSF2608Z T.SCREW 16 FOR C.GEAR BASE
28 VKS3702-00FMM DRIVE UNIT 1
29 LV20466-001A MECHA HOLDER A 1
30 VKL7767-00C BRAKET ASSY 1
31 QYSBSF2606Z SCREW 2 FOR BRACKET
32 VKM3860-00B MCHA HOLDER ASS 1
33 VKL7802-00C M.HOLDER C AS'Y 1
34 QYSDST2604Z SCREW 3 FOR M.HOLDER C
35 VKL7810-00A LIFTER ASS'Y R 1
36 VKL7811-00A LIFTER ASS'Y L 1
37 VKL7812-00A LIFTER ASS'Y H 1
38 VKL2732-002 LIFTER BASE 1
39 VKM3857-001 LIFTER BRACKET 1
41 WDL266035-2 SLIT WASHER 1
43 VKS5514-002MM LOCK LEVER 3
44 VKY3133-002MM RETURN SPRING 1
46 VKY3134-003MM CLICK SPRING 1
47 VKS2252-00F TRAY ASS'Y 3
48 VKS2250-003 TOP BRACKET 1
49 VKS5515-002 S.TRAY STOPPER 1
50 VKW5156-004 TORSION SPRING 1
51 VKS3703-00J CLAMPER ASS'Y 1
62 LV41120-001A INSULATOR 2
63 LV41120-002A INSULATOR 2
65 ----------- DVD MECHA 1
69 QGB2012J1-10 CONNECTOR 1
71 VKW5187-001 ROD 1
72 LV41119-001A SPECIAL SCREW 2
75 LV41568-002A SHEET 6
76 LV41571-001A SPACER 1
To Next Page
