JVC XV-S42SL Service Manual

XV-S40BK/XV-S42SL/XV-S45GD
XV-S30BK/XV-E100SL
1-36
+
–
GND
B.P.F
VCC Vout
Amp. Limiter
Integrator Comparator
Demodulator
GP1U271X (IC801) : Receiver for remote
2
2.Block diagram
1.Terminal layout
IC-PST9140-T (IC702) : System Reset IC
Output GNDInput
1
3
OP1
CO1
Input
Output
GND
CY24203SC-X (IC571) : MPEG/Audio clock generator with VCXO
1
2
3
4
8
7
6
5
XIN
VDD
VCXO
VSS
XOUT
27M
13.5M
16.9344M
1
2
3
4
5
6
7
8
XIN
VDD
VCXO
VSS
16.9344M
13.5
27M
XOUT
Reference crystal input
Power supply
Input analog control for VCXO
Connect to ground
16.9344 MHz clock output
13.5 MHz clock output
27 MHz clock output
Reference crystal output
Pin No. DescriptionSymbol
1.Pin layout 2.Pin function
