Thread color Description
power supply brown Power is positive
（
12-24V DC
）
black Power negative
Communication Yellow (gray) color
485-A
blue 485-B
Note: Please be careful not to connect the wrong wiring sequence,
the wrong wiring will cause the equipment to burn.
The factory default provides 0.6m long wire, customers can
extend the wire as needed or wire in order.
Note that there is no yellow line in the line sequence that may
be provided in some factory batches. At this time, the gray line is
equivalent to replacing the yellow line.
