7
Checking the state of the batteries in the reward launcher
The state of the batteries is checked by flashing indicators on the bottom side of
the launcher.
Charged battery – the green indicator flashes when the reward launcher is switched on.
Low battery – the green and red indicator flashes simultaneously when the reward
launcher is switched on.
If the batteries are discharged, insert new alkaline AA batteries into the reward
launcher.
Switching ON/OFF
To switch on/off the reward launcher, a magnetic switching system is used.
The system is activated by attaching a magnet. The magnet is attached at the
bottom part of the transmitter.
Switching on:
1. Attach the bottom part of the transmitter between the red round target and the
clear LED window on the bottom side of the launcher – the red indicator and then
the green indicator will turn on.
2. Take the transmitter away from the launcher when the green indicator is on. The
green indicator will start flashing.
Switching off:
1. Attach again the bottom part of the transmitter between the red round target
and the clear LED window on the bottom side of the launcher – the green indicator
and then the red indicator will turn on.
2. Take the transmitter away from the reward launcher when the red indicator is
on. The indicators will stop flashing.
Important: When switching on the reward launcher, you need to attach the transmitter
between the red target and the clear LED window of the launcher for approximately 1
second. If you hold the transmitter at the target for more than 5 seconds, the
receiver enters the mode of pairing the transmitter with the launcher. If this
happens, follow the chapter “Pairing the transmitter with the launcher” on pg. 8.
CAUTION: To extend the
battery life, the reward
launcher must always be
turned off after training.
We recommend removing
the battery completely if
you do not use the reward
launcher for a long time.
