9
Maximum Range of the Transmitter
The K-9 BSD-4 can
be used up to 650 ft / 200
m. However, the maximum range is
influenced
by a number of factors – weather, terrain, vegetation, etc.
T
o ensur
e maximum r
ange of y
our device:
Do not cover the antenna at the top of the transmitter.
When transmitting the command, hold the transmitter in the vertical position away
from the body and in the extended arm over your head.
Check the battery in the transmitter and receiver; replace it when necessary.
maximum range regular range minimum range
Features of the Transmitter
The K-9 BSD-4 transmitter allows you to control 4 reward launchers or ball droppers
(buttons numbered 1 to 4). After pressing the button, the launcher will emit a
tone signal. This function serves to alert the dog to the place where his reward in the
form of a launched reward is to be expected. The reward is launched from the
reward launcher by pressing the button. The reward ejection height is up to 9 ft
(3 m) (depending on the weight of the reward used). It is possible to use any reward
up to the diameter of 2.5" / 75 mm. The reward launcher can be hung upright or
supported by the metal support to launch rewards away. The reward can be
launched sideways to the distance up to 18 ft / 6 m.
1. Read these operating instructions again and check whether the problem is
not caused by low batteries or improper use.
2. Make sure that the batteries are inserted with the correct polarity.
3. If the transmitter does not communicate with the reward launcher, try to pair devices
again (see chapter – Pairing the transmitter with the reward launcher on pg. 8).
4. If the launching bowl gets jammed in the bottom position (dirt around the launching
bowl), turn the launcher upside down and tap the ground slightly with it. This will result in
removing any dirt around the launching bowl and the bowl will get unblocked.
5. Contact us if the problem persists.
Troubleshooting
