8. INSTALLATIoN
The KA14 is the height of two rack units (2U) and can be mounted in an EIA-standard 19’’ rack using
two rack adapters (included). In case of installation on a flat surface, use the four rubber pads included.
To maintain a low and even operating temperature, the amplifier contains two fans on the right side.
The figure below shows the air flow:
WARNING:
For effective cooling, do not obstruct the ventilation openings.
