CD1000 Pin Welder Instruction Manual
K.C.D. Studwelding, Cheltenham, Victoria. Tel: 03 9584 1588, Fax: 03 9584 1688
COMPONENT IDENTIFICATION AND LOCATION GUIDE
Component I.D. Description Location
R1 Resistor 470R 2W metal film PCB
R2 Resistor 470R 1W metal film PCB
R3 Resistor 22K 3W metal film PCB
R4 Resistor 220R 2W metal film PCB
R5 N/A
R6 Resistor 47K 2W carbon film PCB
R7 Resistor 10R 3W metal film PCB
R8 N/A
R9 Resistor 220R 1W metal film PCB
R10 wire link PCB
R11 N/A
R12 wire link PCB
R13 Resistor 470R 1W metal film PCB
R14 Resistor 3K3 10W wire wound PCB
R15 N/A
R16 Resistor 47R 4W ceramic wire wound PCB
R17 Resistor 5R 100W wire wound Machine Base
R18 Resistor 100R 75W wire wound Machine Base
VR1 Trimpot 10K 10 turn PCB
VR2 Potentiometer 2K 3W Front Panel
C1 Capacitor 470uF 25volt electrolytic PCB
C2 Capacitor 47nF 400volt polyester PCB
C3 – C4 Capacitor 470uF 25volt electrolytic PCB
C5 – C8 Capacitor 8,000uF 175volt electrolytic Machine Base
D1 – D5 Rectifier diode 1N4004 PCB
D6 Zener Diode 10volt 1N5347B PCB
D7 N/A
D8 Rectifier diode 1N4004 PCB
D9 N/A
D10 Rectifier diode 1N4004 PCB
D11 N/A
To Next Page
