CD1000 Pin Welder Instruction Manual
K.C.D. Studwelding, Cheltenham, Victoria. Tel: 03 9584 1588, Fax: 03 9584 1688
COMPONENT IDENTIFICATION AND LOCATION GUIDE (cont.)
Component I.D. Description Location
D12 wire link PCB
D13 Zener Diode 12volt 1N5349 POS. Weld Terminal
D14 Zener Diode 12volt 1N5349B PCB
D15 Rectifier diode 1N4004 PCB
D16 Rectifier diode skn26/08 Capacitor Bank
Q1 N/A
Q2 – Q3 SCR 2N6399 sensitive gate 25amp PCB
Q4 NPN transistor 2n3904 PCB
Q5 PUT transistor 2N6027 PCB
Q6 N/A
Q7 SCR SKT 340/12E Machine Base
RLY1 Relay 12vDC 4PCO PCB
RLY2 Relay S1200 A240/0013 Machine Base
SW1 Gun trigger switch V-15-3C5 Weld Gun
CB1 Circuit Breaker on/off switch Front Panel
