K. O. LEE B6062 - Clearance Angles -Straight Wheels

Instruction Manual Section Seven
TABLES OF REFERENCE
I. CLEARANCE ANGLES —STRAIGHT WHEELS
Relief Tables for High-Speed Steel Cutters
I—Using Straight Wheels
C = Distance in inches to set center of cutter and tip of
tooth rest below (or above) center of wheel when grinding
with a straight wheel.
—104—
Wheel
Diameter
(Inches)
C for 4º
Relief Angle
C for 5º
Relief Angle
C for 6º
Relief Angle
C for 7º
Relief Angle
.104
.113
.122
.131
.139
.150
.157
.165
.174
.183
.191
.200
.209
.218
.226
.235
.244
.131
.141
.152
.163
.174
.185
.195
.207
.218
.228
.239
.250
.261
.272
.283
.294
.305
.157
.170
.183
.196
.209
.222
.235
.248
.261
.274
.287
.300
.313
.326
.339
.352
.365
.183
.198
.213
.227
.242
.259
.274
.289
.305
.319
.335
.350
.365
.381
.396
.411
.426
