Kaadas Lamborghini Legends - Explosive View

Explosive view
Understanding the installation of a three-dimensional assembly drawing is beneficial to understand lock
structure.
1
13
2 3 4 5 6 7
8 9 10 11
1.Front panel
2.M6 Connecting screw bolt
3. Mortise
4.M5 screws (4)
5.Back panel
6.Upper M6 Screw
7.Back cover
8.Springs (2)
9. Square shaft (2)
10. M5 connecting screw bolt (4)
11. Screws for mounting mortise (4)
12.Mounting Plate
13.Below M6 screw
14. Battery cover
