Kaba E-Flash EF780

EF680/EF780 Installation Guide
Fit Mortice Lock
Before tting the lock ensure the bevelled latch is handed
correctly by rotating latch 180 degrees in either direction
(ensure the face plate is not tted at this time).
• When tting the mortice lock, feed the cable through to
the internal side of the door as you t the lock in place.
• Secure with two 8G x 1” countersunk screws (supplied).
• Install faceplate with two M4 x 8 countersunk screws
(supplied).
Step 2
