Once decided as to which way the door handle is to be
placed
• Turn lock over and insert the guide screw in the necessary
position (as per step 3).
• You may need to use a at head screw driver to tighten
the guide screw.
Note: This guide screw is critical to the alignment of the
mortice lock and furniture and cannot be discarded.
EF680/EF780 Installation Guide
Preparation of Front of Lock
Step 5
Below is the illustration details for the installation of
the guide screw to suit a left hand door installation.
Bottom of lock Top of lock
