Kaco Blueplanet Series User Manual

5. To check the exact network status send the following message to mobile number of the device
SMS Command= *2222#<Stat.gsm>
IMEI
IMEI No. of the data logger (Device Key)
NW
Network
SIGN
Signal Strength out of 31
GPRS
CONT- connected , NC- not connected
PIP
Connected to TrackSo Server or not
CONT- connected, NC- not connected
LOG
no. of data points stored in devices incase of no interet
6. If the GSM light starts flashing 5 times then Login to www.trackso.in
with your Username/Password.
7. Click on ‘Units’ from the menu bar. You will be able to view your installed unit in the table as shown below.
8. Check if the Status becomes Receiveing for the relevant Unit.

Kaco Blueplanet Series Specifications

General

Model	Blueplanet Series
Category	Inverter
Topology	Transformerless
Communication Interfaces	Wi-Fi
Protection Rating	IP65
Nominal Output Voltage	230 V
Output Frequency	50 Hz / 60 Hz
Operating Temperature Range	-25°C to +60°C
