KAESER TF 171E - Parts List

17
PARTS LIST
MAINTENANCE KITS
MODEL TF 171E TF 210E
Standard KRDKT25S KRDKT26S
With Optional Cold Coalescer KRDKT45S KRDKT46S
208-230/3/60 380-420/3/50, 460/3/60, and 575/3/60
PARTS DESCRIPTION TF 171E TF 210E TF 171E TF 210E
Condensing Unit Assembly 5002013 5002015 5002014 5002016
Compressor (Only) 5002921 3227182 5002930 3232811
Fan Motor 5002922 3233153 5002931 3228005
Fan Blade 5002923 3219406 5002923 3219406
Crankcase Heater 3223261 3223261 3223260 3223260
Condenser 5002924 3232832 5002924 3232832
Low Refrigerant Pressure Switch 3230762 3230762 3230762 3230762
High Refrigerant Pressure Switch 3230764 3230764 3230764 3230764
Fan Cutout Switch 1 3230762 3230762 3230762 3230762
Fan Cutout Switch 2 3230763 3230763 3230763 3230763
Hot Gas By-Pass Valve (Air-Cooled) 5002351 5002351 5002351 5002351
Filter Dryer (Liquid Line) 5002925 5002925 5002925 5002925
Temperature Sensor 3210926 3210926 3210926 3210926
Contactor 5002926 5002928 5002926 5002928
AuxiliaryContactor 5004254 5004254 5004254 5004254
Transformer 230/400/460 3159128 3159128 3159128 3159128
Fuse Primary 3223962 3223962 3223962 3223962
Fuse Secondary 4010495 4010495 4010495 4010495
Board, Printed Circuit (EMMII) 3227156 3227156 3227156 3227156
Digital PC Board Fuse 5002943 5002943 5002943 5002943
Power Transformer (575V) N/A N/A 3230895 3230895
575V Transformer Primary Fuse N/A N/A 3049090 3049090
575V Transformer Secondary Fuse N/A N/A 5007288 5007288
Refrigerant High Pressure Switch (H
2
O) 3230764 3230764 3230764 3230764
On-Off Switch 3230777 3230777 3230777 3230777
Cooling Water Regulatory Valve 3232503 3232503 3232503 3232503
Cooling Water Strainer Screen 3230672 3230672 3230672 3230672
