the circuit without a load to measure.
5. Read the measurement result on display. If “OL” is
displayed, it is out of range, select higher range.
WARNING
Pay special attention to safety when measuring
high voltage to avoid electric shock or personal
injury.
Test the known current with the meter before
use to confirm the instrument function is intact.
Resistance measurement
1. Turn the knob to resistance shift and select the
appropriate range;
Note: During measuring an unknown Resistance, use
the maximum range and reduce it until a satisfactory
reading is
obtained.
2. Insert the red probe in “ ” socket and insert the
black probe in “COM” socket;
3. Place the test leads at the both ends of the circuit
or resistance to measure and maintain strong contact;
4. Read the measurement result on display.
