6.5 Roll to roll operation
To work without dust and for easy handling of the laminated prints.
Loading the print roll.
Smaller print roll can be loaded on the print holder shaft delivered with the machine.
This can be loaded
on one of the film storage position
Or on a self blocking shaft on position 4.
Long print roll, rewound on a 3” core mandrel, can be loaded as a waste paper (cf 6.4 b), taking it
under the separation bar.
Loading the rewinding system
• Install a shaft with a carton mandrel on the rewinding position.
Remove the back tray.
