Command
Function Description
Feedback Code
5[x][x]%
Preset MIC volume, [xx] arranges
from [00] to [60].
61 degrees in total.
Volume of MIC:
50
7[x][x]%
Preset line volume, [xx] arranges
from [00] to [60].
61 degrees in total.
Volume of LINE:
50
8[x][x]%
Preset the bass level, [xx] arranges
from [00] to [08].
9 degrees in total.
Bass of LINE: 04
9[x][x]%
Preset the treble level, [xx] arranges
from [00] to [08].
9 degrees in total.
Treble of LINE:
04
Notice:
1: The letter inside bracket [ ] is the variable code, which is the changeable.
2: The bracket [ ] is not included to the RS232 commands.
3: Any dot “.” after the letters is part of the commands.
Example 1:
Switching the input 2 to the line out. We should send the RS232 command: [2A1.]
Example 2:
Turning up the volume of line audio. We should send the RS232 command: [603%]
Example 3:
Preset the MIC volume to “21” degree. We should send the RS232 command: [521%]
Example 4:
Checking the working status of PA2B. We should send the RS232 command: [600%]
