3. Specification
Audio Input
Audio Output
Input
2xstereo audio,
1xMIC
Output
1xamplifier,
1xstereo audio
Input
Connector
2xRCA
1x3.5mm jack
1xcaptive screw
connector,
Output
Connector
1xcaptivescrew
connector
1x3.5mm jack
Input
Impedance
>10KΩ
Output
Impedance
50Ω/stereo,
4~8Ω/Amplifier
Audio General
Frequency
Response
20Hz ~ 20KHz
CMRR
>70dB@20Hz~20KHz
SNR
80dB at maximum
output
Bandwidth
20Hz ~ 25KHz
Stereo
Channel
Separation
>75dB@20Hz to
20KHz
THD + Noise
1%@1KHz,
0.3%@20KHz
at nominal level
Voltage Gain
32dB
Power Output
2x20 Watts (4 Ohms)
Control Function
RS232
Control
RS-232, 9-pin
female D
connector
Pin
Configurations
2 = TX, 3 = RX, 5 = GND
IR Remote
Optional IR remote
TCP/IP
Control
TCP/IP controlled
NOTE: All nominal levels are at ±10%.
