6. RS232 Communication Protocol:
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
Command
Function Description
Feedback Code
1A1.
Switching the audio to input 1
A: 1 -> 1
2A1.
Switching the audio to input 2
A: 2 -> 1
0A0.
Mute Audio of MIC and Line out
Mute Audio
1A0.
Mute audio of MIC
Mute MIC
2A0.
Mute audio of line out
Mute LIN
0A1.
Unmute Audio
Unmute Audio
600%
Checking the working status
A: 1 -> 1
Volume: 30
Bass: 00
Treble: 00
601%
MIC volume up
Volume of MIC:
51
602%
MIC volume down
Volume of MIC:
51
603%
Line volume up
Volume of LINE:
51
604%
Line volume down
Volume of LINE:
51
605%
Bass level up
Bass of LINE:
04
606%
Bass level down
Bass of LINE: 04
607%
Treble level up
Treble of LINE:
04
608%
Treble level down
Treble of LINE:
04
609%
Initialization, back to the default
setting
A: 1 -> 1
Volume: 50
Bass: 04
Treble: 04
