Assembly InstructionsWallaby II
11
Plastic guides
Lift rail
Cable
Lift rail
Rail tabs
Guide Lift onto Lift Rails using plastic guides. Insert ends of cable into rail tabs; make sure the cable is hooked into the rail
tabs on both sides.
Cut the zip tie on the wooden block, but DO NOT remove the block yet.
Push the Lift down to first lock position and remove the wooden block. DO NOT ADJUST LIFT POSITION until the top is
installed, or you risk the Lift coming out and cables becoming disengaged.
Step 4: Lift Panel
