Kangaroo Wallaby II - Page 20

Assembly InstructionsWallaby II
20
Step 6: Doors
180°
180°
c5
K1
K3
K2
K3
c5
5
⁄
8
“ Cam Cover x9
c2
Insert cam bolts on K3 Panels (sides) into cams in Panel K2 (bottom) and tighten cams. Apply c2
Cam Covers.
Insert cam bolts on Panel K1 (front) into cams in Panel K2 (bottom) and K3 Panels (sides). Tighten
cams and apply C2 Cam Covers.
