Technical Specifications
Electrical Specifications
Specification Description
AC Power Input 120/16 VAC, 40 VA, class 2 transformer
Battery Back-up 1battery 12 VDC, 7 Ah, supervised, provides up to 12 hours of operation, Kantech BD7-12
battery tested for 4 hours standby for UL294
Operating
Temperatures
From 2°C to 40°C (35°F to 110°F)
Cabinet Dimensions
(H-W-D)
29.9 cm x 28.8 cm x 7.7 cm (11-3/4 in x 11-3/8 in x 3 in) EMT 1.9 cm (3/4 in)
Cabinet Weight 2.4 kg (5.4 lbs)
PCB Dimension 18.3 cm x 12.18 cm x 5.20 cm (7-1/4 in x 4-3/4 in x 2-1/16 in)
Reader Types Wiegand, proximity, bar code, magnetic, integrated keypad and others
Reader Power Output 12 VDC (11.1 VDC - 13.8 VDC) and 5VDC @ 175mA max, protected and supervised
Monitored Points 4 monitored points, NO/NC, w/without EOL’s (expandable to 12), use UL recognized tamper
switch on cabinet housing to conform with UL 294
Points Maximum Wiring AWG #22 - 600 meters (2,000 feet)
Door Strike Power 12 VDC (11.1 VDC - 13.8 VDC), 250mA max each, supervised
Auxiliary Outputs 4 outputs, 25mA max each, open collector
Relay Controlled Output 2-relay controlled outputs, 25mA max each. Open collector swtiched to ground (use form “C”
relays Kantech #KT-RM1 if needed)
Auxiliary Power Output 11.1 to 13.8 VDC @ 175mA max, protected and supervised
Communication Ports RS-232, RS-485 and Combus
Communication Speed Up to 115.200 baud (automatic detection)
Firmware Flash
Memory
256K
RAM Memory 128K; protected by a lithium battery
Network Autonomy Distributed data and processing
Certifications / Listing FCC Part 15/ICES-003 Class B, Compliant with CE EMC Directive, UL Listed (UL294)
VOLTAGE OUTPUTS MAXIMUM
CURRENT
ABSOLUTE COMBINED
MAXIMUM (N.A.)
ABSOLUTE
COMBINED
MAXIMUM (EU)
Lock Outputs 12 VDC
(11.1-13.8 VDC)
500 mA
(250 mA each)
Auxiliary Power (11.1 to 13.8 VDC) 175 mA
