KAP ROiK-10 - Dip S;W Information

[ANDROID NAVIGATION]
ROiK-10
DIGITAL LVDS OUT
800x480
(Block RGB Signal)
CVBS OUT
Use UART or
Resistive Touch
RGB 800x480
Use Capacitive
Touch
(GOODIX GT9XX)
RGB 480x234
GPS Power Self
(Use car GPS Cable
– Option)
GPS Power from
ROiK-10
(Use External
GLONASS GPS
Antenna – MUST ON)
DIP S/W INFORMATION
ON
OFF
Pin No.
ON OFF
SW - 1
ANALOG RGB OUT DIGITAL LVDS OUT / CVBS OUT
SW - 2
GPS Power from ROiK-10 GPS Power Self
1 2
ON
1 2
ON
1 2
ON
ON
OFF
Pin No. ON OFF
Mode SW - 1
Capacitive Touch
Resistive Touch, UART Touch
Mode SW – 2
(SW – 1 switch is ON)
RGB 480x234 Output RGB 800x480 Output
Mode SW – 3
(SW – 1 switch is OFF)
Interface Using tw8836 Normal
Mode SW - 4
1200x720
(Same Ratio 800x480) - Default
1280x720
1 2
ON
3 4
1 2
ON
3 4 1 2
ON
3 4
1 2
ON
1 2
ON
3 4
1 2
ON
1 2
ON
3 4
1 2
ON
1 2
ON
3 4
1 2
ON
1 2
ON
3 4
1 2
ON
1 2
ON
3 4
1 2
ON
1 2
ON
3 4
1 2
ON
1 2
ON
3 4
Mode SW
SW
