22
Horizontal/Vertical Beam ± 0.1mm/m (0.0001"/")
Self Leveling Range ±5°
Waterproof Standard IP 54 (International
Electrotechnical Commission)
Recommended Working
Range
Indoor 160 ft (50m)
Outdoor 800 ft (250m) with Laser Detector
Laser Source 635 nm laser diode
Classication Laser Class II
Rotational Speed (rpm) 0 (stationary point), 60,120, 300, 600 rpm
Rotational Coverage
(scanning function)
0° (stationary point), 10°,45°, 90°,180°, 360°
Setting slope ±5° (dual axis)
Effective Working
Temperature
4°F —122°F (-20°C — 50°C)
Remote Control Distance Approx. 20m
Remote Control Power
Supply
2 x "AAA" batteries
Laser Power Supply DC 4.8-6V Ni-MH Rechargeable
Laser Battery Life Approx. 20 hours of continuous use One
Laser Detector Power
Supply
One 9V alkaline battery
Laser Detector Battery Life 50 hours of continuous use
Weight 1.8 kg with batteries
Dimensions (LxWxH) 5.5"x5.5"x140) "7x140x180mm)
SPECIFICATIONS
