9. TECHNICAL DATA
Power Connection
Voltage .............................................................230-240 V (AC)
Current...................................................................1~50 Hz
Connected/Load ....................................................... 2.0 KW
Mains Fuse ................................................................ 13 AMP
Water Connection
Supply Temperature (Max)........................................ 60 °C
Supply Rate (Min).................................................... 600 litres per hour
Supply Pressure (Max) .............................................. 12 bar
Supply Hose Length ................................................. 7.5 metres
Diameter .............................................. 1/2 inch
Suction Height from open tank
at Water Temperature 20 °C ....................................... 1 metre
Performance Data
Operating Pressure ............................................20-120 bar
Flow Rate ................................................................ 450 litres per hour
Detergent Intake .....................................................0-25 litres per hour
Optimum Working Distance on High Pressure.......... 30 cm
Hand-transmitted vibration (ISO 5349) .................... 0,8 m/s²
Sound pressure level L
PA
(EN 60704-1) ..................... 74 dB(A)
Sound power level L
WA
(2000/14/EC) ......................... 96 dB(A)
Dimensions
Length...................................................................... 508 mm
Width ....................................................................... 255 mm
Height ...................................................................... 284 mm
Weight ....................................................................... 14 Kg
Circuit Diagramm
C1 Running capacitor
F1 Temperature fuse
M1 Motor
S1 Appliance switch
S2 Pressure-operated switch
