3. GETTING STARTED
3.1 Contents
Upon opening the carton,
if you do not have all the items
as detailed please contact the
Customer Helpline.
1 Transport Bracket
2 High Pressure Hose Reel
3 High Pressure Hose
4 Power Switch (On/Off)
5 Detergent Tank
6 Detergent Suction Tube
(with Filter And Dosing Ring)
7 Mains Electric Lead with Plug
8 Mains Lead Storage
9 Support Leg
10 Hosepipe Connector
11 Inlet Water Connection (with Strainer)
12 Spray Gun
13 Safety Lock Device
14 Four–Way Spray Lance
15 Rorary Wash Brush
Assembly
see Page 19
Assembly
see Page 19
Assembly
see Page 19
