Kärcher BD-405039E - Page 15

9.800-414.0 • Rev. 11/09
PRESSURE WASHER
OPERATOR’S MANUAL
15
H SERIES PUMP EXPLODED VIEW PARTS LIST (CONT.)
KIT NUMBERS 9.804-492.0 9.804-493.0 9.802-629.0 9.802-604.0 9.802-606.0
KIT DESCRIPTION
Plunger Seal
18 mm
Seal Packing
18 mm
Plunger
18 mm
Complete
Valve
Plunger Oil
Seals
ITEMS NUMBERS
INCLUDED
4, 6, 8 4, 5, 6,
7, 8
35, 36, 37,
38, 39, 40
12, 13, 14 3
NUMBER OF CYLINDERS
KIT WILL SERVICE
3 1 1 6 3
ITEM PART NO. DESCRIPTION QTY
41 9.803-294.0 Plunger Rod 3
42 9. 80 3 -157.0 Connecting Rod 3
43 9.802-912.0 Snap Ring 6
44 9.802-915.0 Connecting Rod Pin 3
45 9.802-889.0 Spring Washer 6
46 9.8 02- 937.0 Connecting Rod Screw 6
47 9.803-194.0 "O" Ring Ø2.62 x 152.07 1
48 9.803-166.0 Crankcase Cover 1
49 9. 8 0 3 -197.0 Gasket, G3/8 1
50 9.803-202.0 Sight Glass, G3/4 1
51 9.802-939.0 Cover Screw 5
