9.800-414.0 • Rev. 11/09
PRESSURE WASHER
OPERATOR’S MANUAL
17
M.2 SERIES PUMP EXPLODED VIEW PARTS LIST (CONT.)
ITEM PART NO. DESCRIPTION QTY
42 9.803-144.0 Plunger Rod 3
43 9.803-158.0 Connecting Rod 3
44 9.802-913.0 Snap Ring 6
45 9.802-916.0 Connecting Rod Pin 3
46 9.803-218.0 Spring Washer 6
47 9.803-238.0 Connecting Rod Screw 6
48 8.933-016.0 O-Ring, Ø2.62 x 126.67 1
49 9.803-165.0 Crankcase Cover 1
50 9.803-197.0 O-Ring, Ø1.78 x 14 1
51 9.803-202.0 Sight Glass 3/4 1
52 9.802-939.0 Cover Screw 5
* Available in kit (See below)
REPAIR KIT NO. 8.725-360.0 8.725-362.0 8.725-358.0 8.725-361.0 8.725-363.0 8.725-359.0
KIT
DESCRIPTION
Plunger Seal
4035
6035
18mm
Plunger Seal
4030
5030
20mm
Plunger Seal
3540
15mm
Complete Seal
Packing
4035
6035
18mm
Complete Seal
Packing
4030
5030
20mm
Complete Seal
Packing
3540
15mm
ITEM NUMBERS
INCLUDED
4, 6, 8,
9, 10
4, 6, 8,
9, 10
4, 6, 8,
9, 10
4, 5, 6, 7,
8, 9, 10
4, 5, 6, 7,
8, 9, 10
4, 5, 6, 7,
8, 9, 10
NO. OF
CYLINDERS KIT
WILL SERVICE
3 3 3 1 1 1
REPAIR KIT NO. 9.802-629.0 9.802-620.0 8.933-023.0 9.802-603.0 9.802-609.0
KIT
DESCRIPTION
Plunger
4035
6035
18mm
Plunger
4030
5030
20mm
Plunger
3540
15mm
Complete
Valve
Plunger
Oil Seals
ITEM NUMBERS
INCLUDED
36, 37, 38,
39, 40, 41
36, 37, 38, 39,
40, 41
36, 37, 38, 39,
40, 41
14, 15, 16 3
NO. OF
CYLINDERS KIT WILL
SERVICE
1 1 1 6 3
