Kärcher BD-405039E - Page 19

9.800-414.0 • Rev. 11/09
PRESSURE WASHER
OPERATOR’S MANUAL
19
HHC 930 PUMP PARTS LIST
ITEM PART NO. DESCRIPTION QTY
19 915634 Plug 1/2" 1
20
★
Valve Seat 6
21
★
Valve Plate 6
22
★
Valve Spring 6
23
★
Valve Cage 6
24 735314 Hex Screw 8
25 867750 Bearing Housing 1
26 926649 Bearing Housing O-Ring 2
27 926651 Crankshaft Seal 1
28 808401 Roller Bearing 2
29
▼◆
Spacer 3
30 753100 Crankshaft Key 8 x 7 x 50 1
31 615374 Closed Bearing Housing 1
32 630930 Single-Ended Crankshaft 1
33 926691 Connecting Rod Pin Snap Ring 6
34 914136 Connecting Rod Pin 3
35 928640 Connecting Rod Assembly 3
36 936933 Spring Washer 6
37 735312 Allen Screw 6
38 735313 Crankcase Cover Allen Screw 6
39 858430 Sight Glass 1/2" 1
40 855892 Gasket 1/2" 1
41 915630 Plug 3/8" 1
42 855893 Gasket 3/8" 1
43 826680 Crankcase Cover 1
44 855890 Crankcase Cover Gasket 1
45 829931 Plunger Rod 3
46
✪
Copper Spacer 3
47
✪
Plunger Sleeve 20 mm 3
48
✪
Teflon Ring 3
49
✪
Plunger Sleeve 20 mm 3
50
✪
Copper Spacer 3
51
✪
Plunger Assembly Bolt 3
52 944784 Shim 2
REPLACEMENT PARTS
◆
8.717-582.0 Seal Packing Kit 20 mm 1
▼
8.717-583.0 Complete Seal Packing Kit 20 mm 3
★
8.717-591.0 Valve Assembly Kit 6
✪
8.717-586.0 Ceramic Sleeve Kit 20 mm 3
❖
8.717-585.0 Plunger Seal Kit 1
