– 4
Technische veranderingen voorbehouden!
Technische gegevens
BP 4 BP 6
Spanning V 230 230
Stroomsoort Hz 50 50
Vermogen Pnom. W 700 1000
Max. volume l/h 4600 5000
Max. druk bar 4,3 5,5
Max. hoogte m 43 55
Max. indompeldiepte m 12 27
Max. korrelgrootte van de aan te zuigen vuildeeltjes mm 0,9 0,9
Max. gehalte aan vaste stoffen in het water kg/m
3
1,0 1,0
I/h
m
1000
2000
3000 4000
5000 6000
40
70
60
50
30
20
10
10m = 0,1MPa (1bar)
BP 4 Deep Well
BP 6 Deep Well
Het mogelijke volume is nog zo groot:
- hoe lager de oppomphoogten
- hoe groter de diameter van de gebruikte slangen
- hoe korter de gebruikte slangen
- hoe minder drukverlies het aangesloten accessoire veroorzaakt
24 NL

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kärcher BP 4 Deep Well and is the answer not in the manual?

Kärcher BP 4 Deep Well Specifications

General IconGeneral
Flow rate4600 l/h
Grain size0.9 mm
Maximum delivery height43 m
Maximum operating pressure4.3 bar
AC input voltage230 V
AC input frequency50 Hz
Proper useGarden
Product colorBlack, Metallic
Immersible-
Cable length15 m
Dimensions (WxDxH)102 x 102 x 625 mm
Weight and Dimensions IconWeight and Dimensions
Weight10100 g
