Î Take out the brush roller.
Î Pull the water distribution bar out of the
brush tunnel (Fig. 5, see inside front
cover).
Î Clean the irrigation channel and the
opening in the water distribution bar un-
der running water.
Î Remove the fresh water reservoir from
the appliance.
Î Swivel support bow downward and re-
move the waste water reservoir.
Î Pull the suction tube connection out to-
ward the rear of the appliance and swiv-
el out both ends of the suction tube (Fig.
6, see inside front cover).
The suction tube is separated and both
ends are accessible for cleaning.
Î Pull the vacuum bar off toward the bot-
tom, the suction channel in the cleaning
head is accessible for cleaning (Fig. 7,
see inside front cover).
Î Flush the suction hose and the suction
channel with water or pull or push the
obstruction out with a blunt object.
Clean water distributor
Clean suction tube
Technical specifications
Power
Nominal voltage V 220...2
40
Frequency Hz 1~ 50/
60
Average power con-
sumption
W820
Protective class I
Type of protection IPX4
Vacuuming
Cleaning power, air
quantity
l/s 26
Cleaning power, nega-
tive pressure
kPa 13
Cleaning brush
Working width mm 300
Brush diameter mm 60
Brush speed 1/min 1450
Dimensions and weights
Theoretical surface
cleaning performance
m²/h 200
Fresh/dirt water reser-
voir volume
l4
Length x width x height mm 390 x
335 x
1180
Transport weight
(Adv)
kg 12
(12,5)
Total weight
(Adv)
kg 16
(16,5)
Values determined as per EN 60335-2-72
Hand-arm vibration
value
m/s
2
<2,5
Uncertainty K m/s
2
0,2
Sound pressure level
L
pA
dB(A) 72
Uncertainty K
pA
dB(A) 1
Sound pressure level
L
WA
dB(A) 85
Uncertainty K
WA
dB(A) 1
17EN
