BR/BD 550
New Product Information
Service-Information-
International
No. 90/95 dated 18 Dec 1995
_________________________________________________________________________________________________
International Service Information Page 16/33
Control element BR/BD 550 (mains-powered unit)
Complete printed circuit board
1 Control module A2
2 Terminal strip X4
3 Capacitor C2
4 Capacitor C1
5 Transformer T1
6 Terminal strip X3
7 Solenoid – Brush motor K1
8 Solenoid – Suction turbine K2
9 Transducer T2
