BR/BD 550
New Product Information
Service-Information-
International
No. 90/95 dated 18 Dec 1995
_________________________________________________________________________________________________
International Service Information Page 4/33
1 Push handle
2 Suction bar microswitch
3 Cleaning head
4 Drive wheel
5 Contact pressure of cleaning head
6 Cleaning head microswitch
7 Raise/lower cleaning head
8 Suction bar
9 Dirty-water suction hose
10 Parking brake (battery-powered unit)
11 Parking brake microswitch (battery-
powered unit)
12 Dirty-water drain hose
13 Raise/lower suction bar
14 Safety switch (battery-powered unit)
15 Drive control lever (battery-powered unit)
16 Instrument panel (battery-powered unit)
