25
Maintenance
6. Remove lint and dirt build-up from brush and
housing.
7. Check float and shut-off screen and clean as
necessary.
8. Remove and clean debris tray.
Vacuum Shoe and Hose
NOTE: Vacuum Shoe and hose flush should be done
daily after use. Place machine over drainage area
before beginning.
1. Remove recovery tank.
2. Insert water hose into vacuum hose.
3. With water pressure on high, rinse out hose and
vacuum shoe. Water should flow freely from
vacuum shoe.
Do not allow any water into the vacuum port.
Vacuum Shoe Cleaning
1. Unplug the power cord and move the machine to a
safe level area.
2. To remove the vacuum shoe assembly, spin the
deck around 180 degrees so vacuum shoe is at the
front of the machine,
3. Remove the recovery tank and set to the side.
4. Tip the machine back and let it rest at approxi-
mately a 45 degree angle.
5. Remove the hose from the top of the vacuum shoe.
6. Release (2) steel clips. (as shown below)
7. Rotate the (2) retaining clips (one on each end) to
remove clear vacuum shoe for easy cleaning.
86417210 Operator’s Manual - Armada BRC 40/22 C
