English 7
Safety devices
몇 CAUTION
Risk of injury and damage due to missing or modi-
fied safety devices!
Injuries and material damage
Safety devices must not be bypass, removed or ren-
dered ineffective. Safety devices are provided for your
own protection.
Power switch
The power switch prevents unintentional operation of
the device.
Trigger lock
Note
The trigger can be locked against unintentional opera-
tion by latching the pawl in the groove on the rear han-
dle of the high-pressure gun.
Locking the trigger:
1. Fold up the pawl on the trigger until it latches in the
groove on the rear handle of the high-pressure gun.
The trigger is locked.
Unlocking the trigger:
2. Disengage the pawl from the groove on the rear
handle of the high-pressure gun and fold it onto the
trigger.
The trigger is unlocked.
Thermostat valve on the pump
The thermostat valve opens when the maximum per-
missible water temperature is exceeded and discharges
the hot water outdoors.
Symbols on the device
Installation
Have the screws provided and an appropriate screw-
driver ready.
Install the supplied loose parts onto the device.
Mounting the wheels
1. Position the wheel axle in the mount on the device
frame as shown.
2. Press the spring-loaded pin and push the wheel axle
into the mount until the spring-loaded pin engages in
the hole.
3. Install the second wheel in the same way.
Do not connect the device directly to the
public drinking water network.
Do not direct the high-pressure jet at per-
sons, animals, live electrical equipment
or at the device itself. Protect the device
from frost.
Risk of burns! Do not touch these hot
components.
Danger of poisoning! Never inhale the ex-
haust gases.
