Kärcher HDS 5 - Technical Specifications

– 10
Technical specifications
HDS 5/13 U
*KAP
HDS 5/13
UX *BR
Main Supply
Voltage V 220
Current type Hz 1~ 60
Connected load kW 2,5
Protection (slow) A 16
Type of protection -- IPX5
Protective class -- I
Water connection
Max. feed temperature °C 30
Min. feed volume l/h (l/min) 500 (8,3)
Suck height from open container (20 °C) m 0,5
Max. feed pressure MPa (bar) 0,6 (6)
Inlet hose diameter (min.) Inch 1/2
Inlet hose length (min.) m 7,5
Performance data
Water flow rate l/h (l/min) 450 (7,5)
Operating pressure of water (using standard nozzle) MPa (bar) 12,5 (125) 10,0 (100)
Max. excess operating pressure (safety valve) MPa (bar) 18,0 (180) 15,0 (150)
Max. operating temperature of hot water °C 80
Detergent suck in l/h (l/min) 0-33 (0-0,6)
Burner performance kW 26
Maximum consumption of heating oil kg/h 2,7
Max. recoil force of trigger gun N 21,4
Size of standard nozzle (UX) -- 031
Values determined as per EN 60335-2-79
Noise emission
Sound pressure level L
pA
dB(A) 76
Uncertainty K
pA
dB(A) 3
Sound pressure level L
WA
+ Uncertainty K
WA
(UX) dB(A) 93
Hand-arm vibration value
Hand spray gun m/s
2
1,1
Spray lance m/s
2
0,7
Uncertainty K m/s
2
0,3
Fuel
Fuel -- Fuel oil EL or Diesel
Amount of oil l 0,1
Oil grade -- Motor oil 0W40 (6.288-
219)
Dimensions and weights
Length x width x height (UX) mm 618 x 618 x 994 (1163)
Typical operating weight (UX) kg 70 (76)
Fuel tank l 6,5
13EN
