9.801-509.0 - C • Karcher Operator's Manual
SYMBOLS
Pump Switch
Detergent
Steam Combination
Hour Meter
Motor Overload
When the light is on, it means the overload is tripped.
Reset overload.
Pilot Light
When the light is on, it means there is power to the pilot control.
If there is no light, see troubleshooting guide.
Voltage
When the light is on, it means power supply is on
Burner Switch
Not all machines have all symbols
Identifi cation of Operational Label Symbols
