Kärcher K 2 Compact Operating Instructions

English 11
The warranty terms published by the rele-
vant sales company are applicable in each
country. We will repair potential failures of
your appliance within a one year warranty
period free of charge, provided that such
failure is caused by faulty material or de-
fects in manufacturing. In the event of a
warranty claim please contact your dealer
or the nearest authorized Customer Ser-
vice centre. Please submit the proof of pur-
chase.
Addresses can be found under:
www.kaercher.com/dealersearch
1 Year Warranty Technical specifications
Electrical connection
Voltage 220-240
1~50-60
V
Hz
Power consumption 6 A
Protection class IP X5
Protective class II
Mains fuse (slow-blow) 10 A
Water connection
Max. feed pressure 1,2 MPa
Max. feed temperature 40 °C
Min. feed volume 8 I/min
Performance data
Working pressure 7,4 MPa
Max. permissible pressure 11 MPa
Water flow rate 5,5 I/min
Max. flow rate 6,0 I/min
Detergent flow rate 0,3 I/min
Recoil force of trigger gun 11 N
Dimensions and weights
Length 279 mm
Width 177 mm
Height 443 mm
Weight, ready to operate
with accessories
4,7 kg
Subject to technical changes.

Kärcher K 2 Compact Specifications

General

Pressure	110 bar
Flow Rate	360 L/h
Motor Power	1.4 kW
Area Performance	20 m²/h
Inlet Temperature	40 °C
Voltage	220-240 V
Frequency	50-60 Hz
Hose Length	4 m
Weight	3.7 kg
Detergent Tank Capacity	Not applicable
