Kärcher K 2 Power Control User Manual

10 English
Warranty
The warranty conditions issued by our relevant sales
company apply in all countries. We shall remedy possi-
ble malfunctions on your appliance within the warranty
period free of cost, provided that a material or manufac-
turing defect is the cause. In a warranty case, please
contact your dealer (with the purchase receipt) or the
next authorised customer service site.
(See overleaf for the address)
Technical data
Subject to technical modifications.
EU Declaration of Conformity
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements in the EU Directives, both in its basic design
and construction as well as in the version placed in cir-
culation by us. This declaration is invalidated by any
changes made to the machine that are not approved by
us.
Product: High-pressure cleaner
Type: 1.673-xxx
Currently applicable EU Directives
2000/14/EC
2014/30/EU
2006/42/EC (+2009/127/EC)
2011/65/EU
Harmonised standards used
EN 50581
EN 55014-1: 2017
EN 55014-2: 2015
EN 60335-1
EN 60335-2-79
EN 61000-3-2: 2014
EN 61000-3-3: 2013
EN 62233: 2008
Conformity evaluation procedure used
2000/14/EC: Appendix V
Sound power level dB(A)
Measured: 88
Guaranteed: 90
The undersigned act on behalf and under the power of
attorney of the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Ph.: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2020/08/01
Electrical connection
Voltage V 220-240
Phase ~ 1
Frequency Hz 50-60
Current consumption A 6
Degree of protection IPX5
Protection class II
Power protection (slow-blowing) A 13
Water connection
Feed pressure (max.) MPa 1,2
Input temperature (max.) °C 40
Input amount (min.) l/min 8
Device performance data
Operating pressure MPa 7,4
Max. permissible pressure MPa 11,0
Water flow rate l/min 5,5
Maximum flow rate l/min 6,0
Detergent flow rate l/min 0,3
High-pressure gun recoil force N 11
Dimensions and weights
Typical operating weight kg 4,8
Length mm 246
Width mm 280
Height mm 586
Determined values in acc. with EN 60335-2-79
Hand-arm vibration value m/s
2
<2,5
Uncertainty K m/s
2
0,3
Sound pressure level L
pA
dB(A) 74
Uncertainty K
pA
dB(A) 3
Sound power level L
WA
+ K uncer-
tainty
WA
dB(A) 90
Chairman of the Board of Management
Director Regulatory Affairs & Certification
H. Jenner
S. Reiser

Kärcher K 2 Power Control Specifications

General

Flow Rate	360 L/h
Max Water Feed Temperature	40°C
Area Performance	20 m²/h
Power Consumption	1400 W
Voltage	220-240 V
Hose Length	5 m
Pressure	110 bar
Motor Power	1.4 kW
