English 15
may only be performed at washing stations with an oil
separator.
Working with detergents may only be performed on
watertight surfaces with connection to the waste
water sewage system. Do not allow detergent to enter
waterways or the soil.
Extraction of water from public waterways is not
permitted in some countries.
Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.de/REACH
Intended use
Use the high-pressure cleaner in private households
only.
The high-pressure cleaner is intended for cleaning ma-
chines, vehicles, buildings, tools, façades, terraces,
garden machines etc. using a high-pressure water jet.
Accessories and spare parts
Only use original accessories and original spare parts.
They ensure that the appliance will run fault-free and
safely.
Information on accessories and spare parts can be
found at www.kaercher.com.
Scope of delivery
The scope of delivery for the appliance is shown on the
packaging. Check the contents for completeness when
unpacking. If any accessories are missing or in the
event of any shipping damage, please notify your deal-
er.
Description of the device
The maximum amount of equipment is described in
these operating instructions. Depending on the model
used, there are differences in the scope of delivery (see
packaging).
For the illustrations, refer to the graphics page
Illustration A
Illustration B
1 Stand with carrying handle
2 Water connection with integrated sieve
3 Transport wheel
4 Hose guide
5 Trigger "0/OFF" / "I/ON"
6 Storage for spray lance
7 High-pressure hose
8 *Plug 'n' Clean detergent bottle
9 Storage / parking position for high-pressure gun
10 3-in-1 multi-jet spray lance with 3 spray types (see
also chapter Smart Control System)
11 Smart Control high-pressure gun
12 LCD display (see also chapter LCD display)
13 Battery compartment lock
14 Battery compartment
15 “+/-” buttons for pressure control
16 High-pressure gun lock
17 Button for separating the high-pressure hose from
the high-pressure gun
18 High-pressure gun lever
19 Transport handle, telescoping
20 Carrying handle
21 Hose holder
22 High pressure hose reel
23 Crank handle for hose reel
24 Type plate
25 Accessory compartment
26 Hook for net attachment
27 Accessory compartment net
28 Mains connection with mains plug
29 Water connection coupling
30 **Garden hose (fabric reinforced, diameter at least
1/2 inch (13 mm), length at least 7.5 m, with com-
mercially available quick coupling)
31 **KÄRCHER suction hose for water supply from
open containers (order no. 2.643-100.0)
* optional, ** additionally required
LCD display
Illustration C
1 Area of application (1-SOFT / 2-MEDIUM / 3-HARD
with 2 pressure levels each)
2 BOOST function indicator
3 Spray type recommendation (flat stream/detergent/
dirt blaster)
4 Display Bluetooth
®
connection
5 Signal strength status (four levels)
6 Battery status (empty, almost empty, medium, full)
7 Detergent level (1 / 2 / 3)
Installation
For the illustrations, refer to the graphics page.
Fit the supplied loose parts onto the device before start-
ing up the device.
Have the included screws and the appropriate screw-
driver ready.
Mounting the accessory net
1. Hang the accessory net on the hooks.
Illustration D
Push the high-pressure hose through the
hose guide
1. Insert the high-pressure hose through the hose
guide from the rear.
Illustration E
Installing the water connection coupling
1. Screw the water connection coupling onto the water
connection on the device.
Illustration F
