Kärcher K Mini User Manual

– 8
You can rectify minor faults yourself with the help of the
following overview.
If in doubt, please consult the authorized customer ser-
vice.
 DANGER
Risk of electric shock.
 Prior to all work on the appliance, switch off the ap-
pliance and pull the power plug.
 Pull on the lever of the trigger gun; the device will
switch on.
 Check whether the voltage indicated on the type
plate corresponds to the voltage of the mains sup-
ply.
 Check the mains connection cable for damages.
 Check setting at the spray lance.
 Check water supply for adequate delivery rate.
 Appliance ventilation: Switch the appliance on with
the high-pressure hose detached and operate
(max. 2 minutes) until the water exits the high-pres-
sure connection without bubbles. Switch off appli-
ance and reconnect high-pressure hose.
 Pull out the sieve in the water connection using flat-
nose pliers and clean under running water.
 Clean high-pressure nozzle: Remove dirt and de-
bris from the nozzle bore, using a needle and rinse
through with water from the front.
 Check water flow quantity.
Gear defective, contact Customer Service.
 Slight leakage from the appliance pump is normal.
If the leakage increases contact the authorized
customer service.
Only use original accessories and spare parts, they en-
sure the safe and trouble-free operation of the device.
For information about accessories and spare parts,
please visit www.kaercher.com.
The warranty terms published by the relevant sales
company are applicable in each country. We will repair
potential failures of your appliance within the warranty
period free of charge, provided that such failure is
caused by faulty material or defects in manufacturing. In
the event of a warranty claim please contact your dealer
or the nearest authorized Customer Service center.
Please submit the proof of purchase.
Addresses can be found under:
www.kaercher.com/dealersearch
Subject to technical changes.
Troubleshooting
Appliance is not running
Pressure does not build up in the appliance
Strong pressure fluctuations
Unusual operating noises
Appliance is leaking
Accessories and Spare Parts
Warranty
Technical specifications
Electrical connection
Voltage 220-240
1~50-60
V
Hz
Power consumption 6 A
Protection class IPX5
Protective class II
Water connection
Max. feed pressure 1,2 MPa
Max. feed temperature 40 °C
Min. feed volume 7 I/min
Performance data
Working pressure 7,4 MPa
Max. permissible pressure 11 MPa
Water flow rate 5,5 I/min
Max. flow rate 6,0 I/min
Recoil force of trigger gun 11 N
Dimensions and weights
Length 279 mm
Width 234 mm
Height 297 mm
Weight, ready to operate with accessories 4,7 kg
8 EN

Kärcher K Mini Specifications

General

Maximum flow rate	360 l/h
Working pressure (max)	110 bar
Working pressure (min)	20 bar
Maximum area performance	20 m²/h
Maximum input water temperature	40 °C
Form factor	Compact
Hose length	5 m
Power source	Electric
Water filter	Yes
Product color	Black, Yellow
Detergent tank	-
Pressure range	High-pressure
Connected load	1400 W
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Package height	5600 mm

Weight and Dimensions

Weight	3900 g
