Page #73 background image
– 7
Tekniska data
Puzzi 8/1 C
Nätspänning V 220-240
Frekvens Hz 1~ 50/60
Skydd -- IPX4
Skyddsklass II
Effekt fläktmotor (max) W 1380
Märkeffekt fläktmotor W 1200
Luftmängd (max.) l/sek 61
Undertryck (max.) kPa (mbar) 23 (230)
Effekt sprutpump W 40
Spruttryck MPa 0,1
Spruttryck (max.) MPa 0,3
Sprutmängd l/min 1
Rengöringslösningens temperatur (max) °C 50
Påfyllningsmängd färskvatten l 8
Påfyllningsmängd smutsvatten l 7
Längd x Bredd x Höjd mm 575 x 330 x 445
Typisk driftvikt kg 9,8
Omgivningstemperatur (max.) °C +40
Beräknade värden enligt EN 60335-2-68
Ljudtrycksnivå L
pA
dB(A) 71
Osäkerhet K
pA
dB(A) 1
Hand-Arm Vibrationsvärde m/sek.
2
<2,5
Osäkerhet K m/sek.
2
0,2
Nätkabel H05VV-F 2x1,0 mm
2
Artikelnr. Kabellängd
EU 6.647-263.0 7,5 m
GB 6.647-264.0 7,5 m
CH 6.647-265.0 7,5 m
73SV

Table of Contents

Other manuals for Kärcher Puzzi 8/1 C

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kärcher Puzzi 8/1 C and is the answer not in the manual?

Kärcher Puzzi 8/1 C Specifications

General IconGeneral
TypeDrum vacuum
Cleaning typeWet
Dust capacity- L
Product colorBlack, Grey, Yellow
Dust container typeBagless
Cord length7.5 m
Carrying handle(s)Yes
Maximum area covered18 m²
Clean water tank capacity8 L
Dirty water tank capacity7 L
Airflow61 l/s
Proper useProfessional
Noise level- dB
Cleaning surfacesCarpet, Hard floor
Vacuum air filteringWater
AC input voltage220-240 V
AC input frequency50 - 60 Hz
Maximum input power1200 W
Annual energy consumption- kWh
Weight and Dimensions IconWeight and Dimensions
Depth530 mm
Width330 mm
Height440 mm
Weight9800 g
