English 15
scribed in the chapter Connecting the
cleaning robot to WLAN and the app.
 Follow the step by step instructions
of the app.
Setting up virtual walls
Virtual walls and restricted areas pre-
vent the cleaning robot from entering
areas that should not be cleaned.
Virtual walls can only be set up with the
app. Downloading the app is described
in the chapter Connecting the cleaning
robot to WLAN and the app.
 Follow the step by step instructions
of the app.
Activating mapping
The cleaning robot starts from the
charging station and automatically up-
dates its map after completing a clean-
ing task and after charging.
Mapping can only be set up with the
app. Downloading the app is described
in the chapter Connecting the cleaning
robot to WLAN and the app.
Note
To avoid losing the map, wait a few
seconds after the first mapping until
the map is saved.
 Follow the step by step instructions
of the app.
Operation
ATTENTION
Damage due to moisture
Remove the wiper cloth with the wiper
cloth holder before charging and when
not in use, see chapter Removing the
wiper cloth holder.
Remove the water reservoir before
charging and when not in use, see
chapter Removing the water reservoir.
Protect carpets with virtual walls, see
chapter Setting up virtual walls.
Switching on the cleaning robot
Note
Place the cleaning robot directly on the
charging station if it cannot be
switched on due to a low charge level,
see chapter Initial commissioning.
1. Keep the On / Off button pressed
when the cleaning robot is in stand-
by and not on the charging station.
The signal light flashes for approx.
15 seconds while the cleaning robot
starts up and then lights up continu-
ously.
The cleaning robot emits an acous-
tic signal after the start-up is com-
pleted.
2. Place the cleaning robot directly on
the charging station.
3. Press the On / Off button.
During initial start-up, the cleaning
robot starts mapping.
In operation, the cleaning robot
starts cleaning.
Setting the cleaning modes
Cleaning modes can only be set up
with the app. Downloading the app is
described in the chapter Connecting
the cleaning robot to WLAN and the
app.
The following cleaning modes are
available:
● Dry cleaning
● Combo cleaning
● Wet cleaning
In each of the cleaning modes, the suc-
tion performance and the amount of
water can be adjusted.
Suction performance:
● Quiet
● Standard
● Medium
● Turbo
Water quantity:
● Low

Kärcher RCV 5 Specifications

General

Product type	Accessory kit
Brand compatibility	Kärcher
Suitable for vacuum cleaner type	Robot vacuum
Number of pads	1
Number of brushes	3
Number of filters	2 pc(s)
Quantity per pack	6 pc(s)
Package weight	400 g

Weight and Dimensions

Depth	190 mm
Width	125 mm
Height	82 mm
Weight	100 g
