Kärcher SC 3 Upright EasyFix User Manual

12 English
Switching the device on
ATTENTION
Damage to the device and material
damage through tipping over
The device can fall over and be dam-
aged if inadequately secured during
work breaks or storage. Liquid can also
escape and damage the floor covering.
Position the device with the floor noz-
zle on a solid base or the anti-slip han-
dle vertically positioned on a solid wall.
ATTENTION
Device damage due to incorrectly
set water hardness
The decalcification cartridge only
works properly if the device is adjusted
to the local water hardness. The device
may calcify if the water hardness is set
incorrectly.
Adjust the device to the local water
hardness before operating it for the
first time, see chapter Setting the wa-
ter hardness.
Note
Please ensure that steam stage 3
(tiles/stone) is set, otherwise the warm-
up time frame will be longer.
1. Place the device on a solid surface.
2. Plug the cord into an outlet.

3. Press the On switch.
4. The LED operating indicator flashes
red.
5. The LED operating indicator lights
up constantly green after approx. 30
seconds.
The device is ready for use.
ON
30 sec.

Kärcher SC 3 Upright EasyFix Specifications

General

Type	Steam mop
Capacity	0.5 L
Control type	Buttons
Product color	Black, Grey, Yellow
International Protection (IP) code	IPX4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Ready time	0.5 min
Steam pressure	- bar
Adjustable steam	Yes
Continuous steam performance	40 g/min
Cable length	5 m
Steam-ready light	-

Weight and Dimensions

Depth	314 mm
Width	207 mm
Height	1185 mm
Weight	3100 g
