Kärcher SC 3 Upright EasyFix User Manual

English 13
Regulating the steam volume
The steam volume setting depends on
the surface to be cleaned.
 Press the button with the direction ar-
rows on the handle repeatedly until
the desired steam stage is selected.
3 different steam stages are available:
Note
The maximum steam stage (tiles/
stone) is always selected when the de-
vice is switched on.
● Press the steam lever after setting
the steam volume.
Refilling water
Note
The water level can be seen through
the transparent fresh water reservoir.
When refilling the water, the decalcifi-
cation cartridge remains secured in the
device.
 Open the water reservoir cover and
fill the water reservoir with MAX 17
oz. (0.5 L) tap water, directly at the
device.
or
 Remove the water reservoir, open
the water reservoir cover and fill the
water reservoir with MAX 17 oz. 
(0.5 L) tap water, see chapter Filling
water.
Tiles/stone - maximum
steam stage
Carpet - medium steam
stage
Wood - minimum steam
stage
MAX 17 oz.
(MAX 0.5 L)
MAX 17 oz.
1.
2.
3.
(MAX 0.5 L)

Kärcher SC 3 Upright EasyFix Specifications

General

Type	Steam mop
Capacity	0.5 L
Control type	Buttons
Product color	Black, Grey, Yellow
International Protection (IP) code	IPX4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Ready time	0.5 min
Steam pressure	- bar
Adjustable steam	Yes
Continuous steam performance	40 g/min
Cable length	5 m
Steam-ready light	-

Weight and Dimensions

Depth	314 mm
Width	207 mm
Height	1185 mm
Weight	3100 g
